Serrated Flooring – Pressure Locked

Pressure locked gratings Type-PLS are high quality pressed gratings with anti-slip properties. Framed panels are manufactured to custom-sizes for applications such as walkways, decking, service platforms, ventilation grilles and escape stairs.

Composition & Appearance:

Gratings are supplied with fixing clips to clamp the panel to the support structure.

Panels and support steelwork are supplied hot-dip galvanized with an option for an additional polyester powder coating to any RAL colour.

Heel-Proof Gratings (Type-PLS):

Pressed gratings manufactured with serrated transverse bars. They are available in the following mesh sizes (c/c): 33×11, 44×11, 55×11 and 66×11 mm with a 10×2 mm transverse bar.  The bearing bar can vary from 25×2 mm to 40×3 mm to meet different loading/span requirements.




General Purpose Gratings (Type-PLS):

Pressed gratings manufactured with serrated transverse bars and plain or serrated bearing bars. They are available in the following mesh sizes (c/c): 22×22, 22×66, 25×66, 33×33, 33×66, 44×22, 66×22 and 66×33 mm. The bearing bar can vary from 25×2 mm to 40×3 mm to meet different loading/span requirements.
